MPCQL-12D MPCQL-10D MPCQL-8D MPCQL-5D Mining crawler type flatbed truck
Share to
- 产品描述
-
Product Introduction
MPCQL series mining crawler flatbed truck is mining material transportation equipment powered by compressed air, and it is suitable for tunnel engineering such as coal mines and metal mines, and also suitable for material transportation, handling, traction and other work. The equipment does not require power connection, and it is safe and reliable, easy to operate, and has high work efficiency. It can meet the needs of working in complex road conditions.
Features of the mining crawler type flatbed truck
1.The power source is compressed air, and the pneumatic motor is driven by a hydraulic pump. It does not require electricity and can work by connecting it to the air duct;
2.The crawler type traveling transportation of materials reduces labor intensity for workers;
3.The front and rear dual operation control valves adopted effectively solves the problems of insufficient space and inconvenient turning in the tunnel.
4.Adopting a high-power dual speed travel motor, it can switch between high and low speed;
5.With a large load capacity and an overall width of only 1,100mm,it can be used in narrow working conditions;
6.For multiple uses, it can be used as a handling and transportation tool as well as a tractor;
7.With strong pass abilities and a climbing range of ±20°, it can adapt to various complex working conditions;
8.The travel reducer is equipped with a built-in brake, which automatically locks when parking to prevent the truck from slipping;
9.The truck body is equipped with four telescopic legs, making it safer to lift materials;
10.It can adapt to various complex road conditions thanks to its high-power travel motor hydraulic drive, high traction force, moderate ground specific pressure of the crawler, small overall width, and built-in brake of the travel reducer;
11.The transporter is provided with a telescopic crane arm, with a rated load capacity of 1,500kg and a lifting range radius of 2m, ensuring safe and convenient loading and unloading of heavy objects.
Product Parameters
Mining crawler type flatbed truck
Basic performance parametersItem Unit MPCQL-12D MPCQL-10D MPCQL-8D MPCQL-5D Whole rig Overall dimensions
(L×W×H)mm 3850×1100×2100(±50) 3850×1100×2100(±50) 3850×1100×2100(±50) 3850×1100×2100(±50) Minimum curve radius mm 1900 1900 1900 1900 Minimum terrain clearance mm 300 300 300 300 Rig weight kg 3000 3000 2200 2200 Rated load kg 12000 10000 8000 5000 Traction force KN 45 40 40 38 Ground specific pressure MPa 0.1 0.1 0.098 0.062 Noise Sound pressure level dB(A） 90 90 90 90 Sound power level dB(A） 100 100 100 100 Capacity of flatbed
carriage
（L×W×H)mm 3000×1000×300(±50) 3000×1000×300(±50) 3000×1000×300(±50) 3000×1000×300(±50) Hydramatic pump station Rated pressure MPa 25 25 25 25 Rated flow L/min 80 80 65 65 Pneumati cmotor Model - PBDY063 PBDY063 PBDY040 PBDY040 Working air pressure MPa 0.5 0.5 0.5 0.5 Gas consumption L/min 15 15 13.2 12.5 Power kw 15.5 15 14.2 11 Oil pump Pressure MPa 22 20 19 16 Displacement ml/r 40 40 40 40 Oil tank capacity L 150 150 150 150 Travel
mechanismTraveling mode - Crawler type Crawler type Crawler type Crawler type Drive mechanism type - Hydraulic motor Hydraulic motor Hydraulic motor Hydraulic motor Working pressure MPa 22 20 19 16 Characteristics of travel mechanism - Hydraulic motor
drive, crawler travelHydraulic motor
drive, crawler travelHydraulic motor
drive, crawler travelHydraulic motor
drive, crawler travelBraking mode - Fail safe type Fail safe type Fail safe type Fail safe type Travel speed m/min 35 35 35 35 Gradcability （°） ±20 ±20 ±20 ±20 Lifting device Maximum lifting weight Kg 1500 1500 1500 1500 Telescopic stroke mm 700 700 700 700 Maximum lifting height mm 3000 3000 3000 3000 Crane arm rotation angle ° 360 360 360 360
